Uflex UP28R Rear Mount Helm 1.7 cu. 3-4″ Tapered Stainless Steel Shaft

MPN: UP28R

SKU: CW75560

Uflex UP28R Rear Mount Helm 1.7 cu. 3-4" Tapered Stainless Steel Shaft
Uflex USA

Uflex UP28R Rear Mount Helm 1.7 cu. 3-4″ Tapered Stainless Steel Shaft

MPN: UP28R

SKU: CW75560

OEM
Parts

Shop &

The UP28R Rear Mount Helm features a compact design with a 1.7 cu. displacement and a 3/4" tapered stainless steel shaft. It includes a built-in lock valve and an integral relief valve for enhanced safety. The pump is suitable for various applications, ensuring durability and longevity. Its user-friendly design allows for easy maintenance and replacement.

Features
  • Available in four different displacement sizes
  • Ball bearing piston race
  • Built-in lock valve for positive rudder lock
  • Cast iron cylinder rotor for greater durability
  • Includes 90? adjustable fittings for 3/8? tube

2 in stock

$685.29

Uflex USA

2 in stock

Free Shipping

OEM Parts

With 2-Day Shipping

Get By Saturday 02/07

30 Day Returns

Click to read our policy

Same Day Shipping

Order before 3PM EST

Marine
Co-Pilot
Marine Co-Pilot
Shopping Assistant

Sample Questions:

What is the weight and length?

Does it come with the motor?

What is the manfu. part number?

Ask Any Question About The Uflex UP28R Rear Mount Helm 1.7 cu. 3-4″ Tapered Stainless Steel Shaft

[mwai_chatbot id="default"]

About your product

UP28R Rear Mount Helm 1.7 cu. 3/4″ Tapered Stainless Steel Shaft

Features:

  • Available in four different displacement sizes
  • Compact design
  • Ball bearing piston race
  • Built-in lock valve for positive rudder lock
  • Integral relief valve for over-pressure protection
  • 3/4” tapered stainless steel shaft
  • Easily accessible lock valve and shaft seal for replacement
  • Cast iron cylinder rotor for greater durability and longer life
  • 1/4″ NPT fitting for 3/8″ tube
  • Includes 90° adjustable fittings for 3/8” tube and white bezel
  • UP45R pump is ideal for double cylinder outboard applications
  • UP45 pump is available also for inboard application
  • X68 (optional) – 40894Z Chrome bezel
  • KITF (optional) – 39664Y Remote fill adapter

Specifications:

  • Mounting: Retro-cruscotto
  • Displacement/Revolution: 28 cc-1.7 cu in
  • # of Pistons: 5
  • Relief Valve Setting: 70 Bar – 1000 PSI
  • Maximum Wheel Diameter: 710mm – 28″
  • Weight: 5kg – 11 lbs.

Manufacturer : Uflex USA
Manufacturer Part No : UP28R
UPC : 702755024811

Installation Guide

Additional information

Weight12.00 lbs
Dimensions12.00 × 7.00 × 7.00 in
Brand

UPC

MPN
